Absolute CM

  • Compact design concept
  • Incinerable
  • ICON9 en1822
Item Type Filter Class EN1822 Width (mm) Height (mm) Depth (mm) Airflow (m3/h) Pressure drop Initial (Pa)
CMM13-305x305x292-P H13 305 305 292 435 250
CMM13-457x610x292-P H13 457 610 292 1470 250
CMM13-610x610x292-P H13 610 610 292 2050 250
CMM13-762x610x292-P H13 762 610 292 2650 250
CMT13-305x305x292-P H13 305 305 292 535 250
CMT13-457x457x292-P H13 457 457 292 1260 250
CMT13-305x610x292-P H13 305 610 292 1155 250
CMM13-305x610x292-P H13 305 610 292 935 250
CMM13-457x457x292-P H13 457 457 292 1050 250
CMT13-457x610x292-P H13 457 610 292 1800 250
CMT13-610x610x292-P H13 610 610 292 2450 250
CMT13-762x610x292-P H13 762 610 292 3110 250

Specifications

Application
HEPA filter for standard applications
Frame
MDF
Media
Glass fiber
Max temperature °C
70ºC
Relative Humidity
100%
Recommended final pressure drop
2x Initial pressure drop
Separator
Hot Melt
Gasket
Polyurethane, endless foamed
Sealant
Polyurethane
Max. final pressure drop
800 Pa
Comment
Remarks: All filters scan tested acc. EN 1822
Other options available: Galvanized frame
