CamCarb PG

A cylindrical, corrosion resistant molecular filter filled with Camfil activated alumina or activated carbon. The most versatile gas phase air filter installed in supply, recirculation, and exhaust air systems in commercial, industrial, and process applications. The design provides the best total cost of ownership for the removal of corrosive, odorous, and irritant gases.

  • Corrosion resistant and low dusting construction
  • 25% lighter than CamCarb CM
  • Inherently leak-free design when installed in dedicated hardware
  • Combines highest removal efficiency and lowest pressure drop
  • Predicted removal efficiency and lifetime by Camfil's proprietary software
  • Typical target gases: hydrogen sulfide, VOCs, ozone, formaldehyde, nitrogen dioxide, and other acids and bases, Corrosion resistant and low dusting construction
  • 25% lighter than CamCarb CM
  • Inherently leak-free design when installed in dedicated hardware
  • Combines highest removal efficiency and lowest pressure drop
  • Predicted removal efficiency and lifetime by Camfil's proprietary software
  • Typical target gases: hydrogen sulfide, VOCs, ozone, formaldehyde, nitrogen dioxide, and other acids and bases
  • ICON6 Molecular
  • ICON14 IAQ_Facility
  • ICON37 ISO10121

Specifications

Application
High removal efficiency of gaseous contaminants from make-up air, eliminates objectionable odors and emissions from recirculated or exhaust air, and Protect sensitive objects from harmful air pollutants
Filter Frame
Plastic molded
Media
Activated Carbon, Impregnated Activated Carbon, Impregnated Activated Alumina
Max temperature (°C)
50
Installation options
Front access frames and side access housings are available. See related products below:
Comment
Twelve (12) panels are applied per 24" x 24" (610 x 610mm) opening.
Maximum face velocity: 500 fpm (2.5 m/s) per opening or 42 fpm (.21 m/s) per panel.
Can be filled with any loose-fill molecular media.
